Home Products SOD-123 SOD-123 Diode SOD-123 Diode Part 2
| Model | PD | VR | IFM | IO | IR | VF | trr | MARKING | |||
| (mW) | (V) | IR(µA) | (mA) | (mA) | (µA） | VR(V) | (V) | IF(mA) | (ns) | ||
| BAT42W | 500 | 30 | 10 | 200 | 0.5 | 25 | 0.65 | 50 | 5 | S7 | |
| BAT43W | 500 | 30 | 10 | 200 | 0.5 | 25 | 0.45 | 15 | 5 | S8 | |
| BAT46W | 500 | 100 | 100 | 150 | 2 | 75 | 1 | 250 | S9 | ||
| BAT54W | 500 | 30 | 100 | 100 | 2 | 25 | 1 | 100 | 5 | L9 | |
| BAV116 | 350 | 130 | 100 | 500 | 215 | 0.005 | 75 | 1.25 | 150 | 3000 | XX |
| BAV16W | 400 | 75 | 10 | 300 | 150 | 1 | 75 | 1.25 | 150 | 4 | T6 |
| BAV19W | 500 | 100 | 10 | 400 | 200 | 0.1 | 100 | 1.25 | 200 | 50 | A8 |
| BAV20W | 500 | 150 | 10 | 400 | 200 | 0.1 | 150 | 1.25 | 200 | 50 | T2 |
| BAV21W | 500 | 200 | 10 | 400 | 200 | 0.1 | 200 | 1.25 | 200 | 50 | T3 |
Thousands Tree established in 2008 with workshops more than 10,000m².We have technology of SOT-23,SOD-123,SOD-323,SOT-23-3,5,6L and DFN1006,DFN1*1-4L packing.
